How To Choose The Right Laser Shutter

As gatekeepers of your laser system, laser shutters play an important part in the operation and safety of various devices. With so many different types available, it can be challenging to identify the right one for your needs.

Our guide on how to choose the right laser shutter will help you understand how to match the right device type to the correct application.

How To Choose the Right Laser Shutter: Factors to Consider

There are many different types of laser shutters, each designed for specific applications. These shutters differ in numerous ways.

To help you narrow down to the correct one, here are the factors to consider before making your choice:

Shutter Type

There are a number of standard types of shutters–categorized according to their design and functionality:

• Mechanical Shutters: These use blades or diaphragms to block light physically. While they are typically designed to last, they often fall short when it comes to switching speeds.
• Acousto-Optical Shutters: This type uses sound waves to deflect or block light. It is characterized by high-speed performance in light modulation. This makes it ideal for applications that require rapid laser beam control.
• Electro-Optical Shutters: They use electrical signals to control light exposure. Though they have relatively high switching speeds, they have some limitations when used in high-power applications.
• Time-Multiplexed Optical Shutters: These have the highest speed and control capabilities. They segment light into timed pulses–supporting ultra-precise manipulation.

To choose the most appropriate type of shutter, take time to understand the specific needs of your application.

Optical Power Handling

Optical power handling refers to the highest possible amount of energy or power that a shutter can withstand without damage.

It is an extremely important consideration for applications involving high-power lasers. Exceeding the power handling capacity of any shutter can cause damage or failure. This can result in unnecessary downtime and expensive repairs.

Choose a shutter whose power handling capacity surpasses the maximum energy level of your laser system. Take into account both the continuous wave power of the laser (pulsed energy) and the beam’s intensity and spot size.

Response Time and Speed

Response time is the duration it takes for a shutter to transition from open to closed state, or vice versa. Speed is the switching frequency. It describes how fast the shutter cycles between the two states.

Applications such as optical communications, high-speed imaging, and laser pulse picking call for high switching speeds and fast response times. The shutter’s specifications should match the required speed for the application.

Durability

Laser shutters often operate in challenging environments and are subjected to repeated cycling. To minimize maintenance costs and get long-term reliability, select a durable shutter constructed using high-quality materials.

Check the expected lifespan as indicated by the manufacturer, as well as its resistance to vibration, humidity, and temperature.

Compatibility with Your Laser System

The right laser shutter has to be compatible with your system for seamless integration and performance. Some of the features to consider include the aperture size, wavelength range, power supply requirements, and control interface.

The aperture size needs to be large enough to accommodate the laser beam without vignetting or clipping. The shutter’s wavelength range has to be compatible with the laser’s operating wavelength. The control interface should work with your system’s electronics. Power supply requirements have to be aligned to your system’s power capabilities.

NM Laser has an extensive collection of laser shutters and optical beam shutters to meet a wide range of application demands. For systems that have unique requirements, we also offer customization options to meet even the most specific application needs.

Manufacturer Reputation

Besides the technical specifications, it is also important to consider supplier reputation before choosing your shutter.

Reputable manufacturers follow stringent quality control standards to meet industry requirements. They are highly knowledgeable. They can give expert advice in the selection, installation, customization, and operation processes.

Additionally, buying from a reputable manufacturer makes it possible to access replacement parts and support when necessary. This can minimize downtime and reduce costs in the long run.

Making the Optimal Choice with NM Laser

NM Laser has been pioneering innovations in laser and optical shutter technologies for 35+ years. In that time, we have established a remarkable track record in supplying the most reliable and durable products in the market.

We manufacture all our products in the USA–meeting all set industry benchmarks for high-quality products designed to last. Our wide range of shutters serves numerous applications. We also offer custom laser shutters to meet unique needs.

Thanks to our over three decades of experience, we have the knowledge and expertise to guide you through the selection process and beyond.

Reach out to our experts today to discuss your laser system needs and get recommendations for the most suitable laser shutter to meet them.
